To flesh out my portfolio a bit more, I decided to make a floor plan concept of a studio apartment that one would see on a real life website for my final project in Vector Based Imaging this semester. Each grey square is a square foot, and things were drawn to depict realistic size.

Image Description:
There is an image of an apartment floor concept with heavy black lines to represent walls and light grey squares to represent a square foot. The door to the apartment is on the right side of the image, entering between the kitchen with a fridge, oven, and sink to the entering person's right and a living room with a couch, coffee table, TV, and walk-in closet to the right. The kitchen is 9 by 9.66 feet. The living room is 10 by 7 feet. The walk-in closet is 5 by 2.5 feet. Going straight, there is a washer dryer unit space that is 2.5 by 2.5 feet. After that, there room to put a queen sized bed, which is 9.33 by 12 feet. To the left, there is a bathroom space that is4.5 by 9.33 feet, with dual sinks to the person's right, a toilet to the immediate left, and a shower/bath unit to the far left in the space.
