Description
Link for Information and Image: modernfirearms.net/en/assault-…

Website: modernfirearms.net/en/

The AM-17 compact assault rifle has a compact upper receiver made from polymer (with steel reinforcements), with integrated Picatinny rail on the top. Lower receiver along with magazine housing and pistol grip is also made from polymer and connected to the upper via two captive cross-pins.

This weapon employs a gas operated action with short stroke gas piston and rotary bolt locking with three radial lugs on the bolt head.
Manual safety/fire selector levers are ambidextrous, and the rifle can fire in single shotsand full automatic. Bolt chargin handle reciprocates with the bolt carrier, and can be installed on either side of the gun, depending on thr user preferences. AM-17 rifle is equipped with a side-folding and adjustable (telescoping) shoulder stock. Stock folds to the right and does not interfere with firing operations.

A quick-detachable tactical sound suppressor can be installed on the muzzle. The AM-17 rifle is fed from standard AK74 compatible magazines. Versions in other calibers use magazines from AK101 in 5.56mm or from AKM or AK-103 in 7.62x39mm.

Specification Value
Full text name AM-17 compact assault rifle (Russia)
Caliber cartridge 5.45x39 7N6 7N10 7N22 7N24
Action type select-fire
Trigger type sa
Overall length, mm 750
Length, folded, mm 490
Weight empty, kg 2,5
Magazine capacity, rounds 30
Cyclic rate of fire, rounds/min 700-850
