Ipandee — Remote meter MH-M80
#meter #remote #solar
Published: 2023-03-22 08:15:54 +0000 UTC; Views: 1304; Favourites: 2; Downloads: 1
Redirect to original
Description
www.ipandee.com/products/remot…
1. Automatically identify and display relevant parameters of connected devices.
2. OLED real-time display of operating data and working status.
3. Six navigated function buttons, make the operation intuitive, convenient and fast.
4. Directly supply power to the display unit from the controller, which requires no additional external power.
5. Support real-time data monitoring, remote load switch, data browsing, and modification of equipment parameters/charging control parameters/load control parameters.
6. Based on the RS485 communication bus, long communication distance.
Technical specifications of HM-M80
Dimension
80mm diameter, 17.5mm high
Mounting hole
3mm
Installation Method
Magnetic suction + screw
Communication interface
RJ45
Supply voltage
4.8V~5.5V
Power Consumption
≤0.5W
Power supply
Connect to controller
Communication
RS485 bus
