MathMod [2015-09-15 11:26:25 +0000 UTC]

Arena!
This model is based on the Scherk minimal surface and it opens the door to very interesting new mathematical objects!
MathMod script;
{
"Iso3D": {
"Name": [
"Arena"
],
"Description": ["Arena-1.0 by Abderrahman Taha 15/09/2015"],
"Component": [
"Arena"
],
"Const": [
"cx=0.0000000000001",
"cy=0.0000000000001",
"cz=0.0000000000001"
],
"Funct": [
"Scherk=sinh(x)*sinh(y)-5*sin(z)",
"Scherk2=Scherk(x,(sqrt(y*y+z*z)-13.5),z,t)",
"Tickness2.6)",
"IsoExterior=Scherk2(x,y,z,t)",
"DFx2(IsoExterior(x,y,z,t)-IsoExterior(x+cx,y,z,t))/cx)",
"DFy2(IsoExterior(x,y,z,t)-IsoExterior(x,y+cy,z,t))/cy)",
"DFz2(IsoExterior(x,y,z,t)-IsoExterior(x,y,z+cz,t))/cz)",
"Rapport2sqrt(DFx2(x,y,z,t)*DFx2(x,y,z,t)+DFy2(x,y,z,t)*DFy2(x,y,z,t)+DFz2(x,y,z,t)*DFz2(x,y,z,t)))",
"Iso3IsoExterior(x-DFx2(x,y,z,t)*Tickness2(x,y,z,t)/Rapport2(x,y,z,t),y-DFy2(x,y,z,t)*Tickness2(x,y,z,t)/Rapport2(x,y,z,t),z-DFz2(x,y,z,t)*Tickness2(x,y,z,t)/Rapport2(x,y,z,t),t))",
"Iso2IsoExterior(x+DFx2(x,y,z,t)*Tickness2(x,y,z,t)/Rapport2(x,y,z,t),y+DFy2(x,y,z,t)*Tickness2(x,y,z,t)/Rapport2(x,y,z,t),z+DFz2(x,y,z,t)*Tickness2(x,y,z,t)/Rapport2(x,y,z,t),t))",
"TickIsoExteriorIso2(x,y,z,t)*Iso3(x,y,z,t))"
],
"Fxyz": [
"if((sqrt(x*x+4*y*y+z*z) - 22)<0 & abs(x)<6 ,TickIsoExterior(x,2*y,z,t), 1)"
],
"Xmax": [
"7"
],
"Xmin": [
"-7"
],
"Ymax": [
"23"
],
"Ymin": [
"-23"
],
"Zmax": [
"23"
],
"Zmin": [
"-23"
]
}
}
