mcsoftware — Tesla Coil (Slayer Exciter) Circuit Animated GIF
#animatedgif #coils #electronics #pcb #raytraced #raytracing #tesla #teslacoil #transformer #transistor #circuitboad #slayerexciter
Published: 2019-02-09 01:28:37 +0000 UTC; Views: 2098; Favourites: 2; Downloads: 21
Redirect to original
Description
Here's a raytraced mini Tesla coil (Slayer Exciter) circuit animation I created. I used a raytracer I wrote. If you want to see a better quality (than animated GIF), more involved (circuit components falling into place) version, go to my video at:www.youtube.com/watch?v=gwSStw…
(You'll also see a lot of electronics stuff (transistors, transformers, electronic kits, etc.) and info on diagnosing a non-working Tesla coil, etc.)
And to see an update on my now working Tesla Coil, go to my video at:
www.youtube.com/watch?v=N6YHpK…
