MEGA DRILL , Made this for one of the competition which i participated recently , the aim was to design and build a machine which works underground , and with heavy specifications like
- Design a ROTUAV
- Must seat at least one person (in 2214 this could be fully automated, but it should still have space for an operator in case something goes wrong)
- Must have some kind of device to move and clear earth in order to create underground tunnels or spaces
- Must have bright lights on the front to facilitate working underground
- Must make contact with the ground i.e. no hovering vehicles
- crush cages
- safety
- the need to operate underground for long periods of time, thus requiring substantial fuel reservoirs as well as lubrication reservoirs
- if this is clearing/ moving earth underground, devices that help move the rock and earth out of the way
I did the basic model in sketch up and then rendered in Photoshop ,,,,again many obstacles out of which i tried to solve most of it but because of timeline i couldn't ,,,, tough time but learned many things in process ,
