wheattthin — rahminKB
#keyboard #potentiometer #mechanicalkeyboard #pcbdesign #kicad #rotaryencoder #mxswitch
Published: 2021-05-21 09:02:17 +0000 UTC; Views: 207; Favourites: 5; Downloads: 0
Redirect to original
Description
PCB in KiCad for a 68 key symmetrical keyboard, with the option to add rotary encoders / potentiometers in the top corners (6 in total)designed with the intent to give the ability to toggle which side your key pad and arrows are on at the press of a key (by using QMK layers for the firmware)
