Afterskies — Whitepoint-class Modular Destroyer, BMD
Published: 2013-06-26 07:16:39 +0000 UTC; Views: 6986; Favourites: 71; Downloads: 232
Redirect to original
Description
Whitepoint-class Modular Destroyer, Ballistic Missile Defense HullLength: 530 feet
Width: 77 feet
Height: 140 feet (from waterline) 153 feet (with draft)
Draft: 33 feet*
Tonnage: 11,000†
Speed: 46 knots
Aircraft: 1†
Boats: 3 RHIBS
Ship's Force: 106†
Air Wing: 18†
Deployed Forces: 24 Troops
Armament:
140 VLS Tubes
2 Torpedo Tubes (Ventral)
Defenses:
3 30mm Shield CIWS
3 25mm Mk3 Rapier Defense Autocannons
5 .50-cal Dagger ROADS
1 NRAM-32 Longsword (24 Missiles each)
60 Active Anti-Torpedo Decoy-Explosives
2 Active SONAR Decoys, towed
8 .50-cal Machine gun posts
Full Command Electronic Warfare & Deterrence Suite
Power & Propulsion
Power Source: 1 D2H 800Mw LMTR
Back up Source: 3Mw Diesel Generators
Battery Back up: 12 Hour life, 4 for propulsion
Propulsion: 4 Asimov Engineering D-2 Waterjets
Secondary Propuslion: 1 Internal Asimov Engineering CV-2 Motor-Propulsors
Tertiary Propulsion: 1 Bow Asimov Engineering D-2 Waterjet, Fixed Orientation Thrust Vectoring
Air:
1 Helipad
Features a Ballistic Missile Defense Long-Range Radar Array
Related content
Comments: 4
Me again!
Ok, except ship stability issue what is the weight of that gigant array ?
👍: 0 ⏩: 1
Not as heavy as it looks. RADAR Arrays aren't exactly my forte, but much of that array assembly is hollow for air recirculation to keep the entire thing cool.
👍: 0 ⏩: 1
You will have an enormus stability problems. It's just too small ship to have that kind of array. And if it is hollow there will be no good air circulation around it, additional problem.
Btw: sorry for all this criticize I don't want to offend you.
👍: 0 ⏩: 1
The criticism is fine.
It's "mostly hollow," as in it involves a great deal of air ducting and fans.
It's not a ship meant to go into a great deal of combat or do any sort of high-speed maneuvers, and would be regularly pulled into port or put further out to sea to avoid high-seas; it's meant to augment large Air Defense commands and watch for ballistic missiles and larger air raids, or possibly monitor large swathes of air over a foreign country.
👍: 0 ⏩: 0
