Description
avro arrow 2 cf-220

General characteristics

* Crew: 1
* Length: 83 ft 9
* Wingspan: 54 ft 0
* Height: 15 ft 6
* Wing area: 1,225 ft²
* Airfoil: NACA 0003.5 mod root, NACA 0003.8 tip
* Empty weight: 50,040 lb
* Loaded weight: 67,920 lb
* Max takeoff weight: 100,605 lb
* 2× G Pratt & Whitney YF220 , 65,000 lbf

Performance

* Maximum speed: Mach 6.6
* Cruise speed: Mach 3.4+ est.hypercruise at altitude
* Combat radius: 900-520 mi[15] (1448.4096 nmi, 1.448.4096 km)
* Service ceiling: 95,000 ft (28.95600m)
* Wing loading: 70 lb/ft² (456 kg/m

# Secondary Powerplant: 1× General Electric/Rolls-Royce F136 afterburning turbofan, >40,000 lbf (178 kN) [in development]
# Lift fan (STOVL): 1× Rolls-Royce LiftSystem driven from either F135 or F136 power plant, 18,000 lbf (80 kN)
# Internal fuel: 35.00 IB

Armament

* Guns: 2 × GAU-22/A 25 mm (0.984 in) cannon in internal mounted
* Hardpoints: 4× external pylons on wings with a capacity of 30,000 lb ( internal mounted on Rotary Launcher Assembly (RLA)[37],
* Missiles: 12 loud
o Internal: 12 air-to-air missiles, or 16 air-to-air missiles and 20 air-to-ground weapons.
o External: 6 air-to-air missiles, or 4 air-to-ground weapons and 2 air-to-air missiles[40] with combinations for the following missiles:
o Air-to-air missiles:
+ AIM-120 AMRAAM
+ AIM-132 ASRAAM
+ AIM-9X Sidewinder
o Air-to-ground weapons:
4× AGM-88 HARM
+ AGM-154 JSOW
+ AGM-158 JASSM

Anti-ship missiles:
2× AGM-84 Harpoon or
4× AGM-119 Penguin
