Electric Powered Bolt Launcher.Powered by a car battery, probably worn in a sling across the back, this device can hurl a sharpened bolt at ranges up to 50m with lethal force.
A small electric motor spins the front four wheels to provide the momentum. The trigger releases a small spring loaded firing pin, which slams the bolt from the canister into the barrel and wheel system. The firing pin has to be manually pulled back before each shot.
