Description
Apperently this idea was already used in Bioshock, unfortunatly I have not played it
BUT the idea is somewhat different in that the rounds are ina chain, and not just in a giant drum. And the chain extends on both sides. The major issue with this is figuring out how to get the chain to cycle. I do have more pics, they just arent scanned yet. I'll link to them when I get that far
It's a break open reload style where you replace the chain and the chain guide as the guide has covers outside the gun to keep the rounds from sliding out. (they arent fixed in the chain so as to alow auto fire.
The gun is also an Automatic. This feature is being reworked. It will will be select fire single/auto. But it's the blowback of the empty shell that recocks the hammer, then as the chain feeds the shell is slid back into place in the chain.
(The blue lines are from the older version that I drew over)
