MBqwertyaaa — 44 Class Driveset Animated
#animated #engine #gear #gmod #linkage #loco #locomotive #piston #rail #railroad #railway #rods #steam #timer #train #valve #walschaerts #animatedgif #mesmerizing
Published: 2015-04-14 23:29:02 +0000 UTC; Views: 879; Favourites: 8; Downloads: 0
Redirect to original
Description
These are the animated drivers showing the full cycle.Related content
Comments: 5
Awesome animation of Walschaerts Valve Gear! If I make a suggestion, I would quarter the drivers so that they are 90 degrees offset. They are currently set at 180 degrees. I can't wait to see this finished!
👍: 0 ⏩: 2
I'm now doing hologram rods. Also, I've learned a lot about the walschaerts valve gear.
I love trigonometry.
👍: 0 ⏩: 0
Actually, this is a physics run "animation." It is finished: fav.me/d8lc8b8 fav.me/d8l7atv
This specific drive 4 is American in make, and is for a duplex. Also, I don't really like the look of 90 degree offsets. It just looks odd.
About your tumblr thing. fav.me/d8ishih This is my first EQRR loco...
👍: 0 ⏩: 0
Lol yeah. Took forever to make it a .gif. (Adobe product /= to photoshop = no .gifs, or even exporting.) ._.
