This is THE project.The Talon is by far the most ambitious undertaking I've attempted yet. I haven't uploaded anything recently because this is all I've been doing. I started the Talon by blueprinting the internals to scale (5px=1mm), which is something I've never done before. Then I developed an outline. Then I found out that outline wouldn't print, because the scale was too large. So I tripled the thickness of the lines, while keeping the scale the same. That's right, each of those lines is three pixels thick. Then I redesigned the blueprint, and redid the line drawing, culminating in the most detailed, most comprehensive product I've ever produced. The Talon is chambered in 6.5 Diamondback, and is intended as a light marksman rifle, capable of as good or better accuracy as the M110 SASS and equal or better range. The weapon is also capable of withstanding great environmental punishment, by using selective tolerances, tight in critical areas, but loose in others. Extensive sand grooves ensure that even in the cruddiest environments, this rifle will still work. The weapon uses a direct-impingement system, which I am confident will be quite reliable after doing studies on the French MAS 49 rifle, a DI weapon that earned laurels for reliability in jungle environments.
The weapon, as shown, has a 20-round box magazine, but also can use 30- or 40-round magazines. The controls are COMPLETELY ambidextrous, with charging handles in identical locations on either side, dual selectors and dual magazine releases. The weapon as shown has a forward sight M1913 rail and a rear sight M1913 rail, and is intended to be used mostly with optics and BUIS. The rails are also to exact scale, something I've also never done. The weapon field strips essentially like an M16, but requires the removal of the charging handles to remove the bolt carrier. The stocks shown are basic, I hope to get around to more detailed and advanced stocks, such as Quad Rail Interface Systems and a collapsible/foldable/adjustable buttstock.
