Concept for Air Cavalry jungle warfare operations.Top left helicopter is an Electronic Warfare unit with remote controlled tail gun. Based partially off the OH-58 Kiowa Warrior Scout Helicopter.
Bottom left is a co-axial rotor gunship based off the UH-1H. This unit is without door gunner. Right side helicopter is same type with door gunner. Machine gun is double feed each belt feeding into one of two barrels. Both are fired with one trigger. Caliber is 15x100mm rounds belt fed.
My first attempt at use of vector masks to create reflected images off window glass.
Update: 25/06/2012 Some quick shadow editing
