tzj — psu conversion
Published: 2011-06-29 22:39:20 +0000 UTC; Views: 318; Favourites: 1; Downloads: 10
Redirect to original
Description
Pic of my psu conversion.Specs: ATX-500w, CWT (channel well technology co, ltd).
-input AC 230v 6a 50hz (115 12a 60hz)
-output
+12v 22a
+5v 38a
+3.3v 30a
-5v 0.5a
-12v 1a
Due to limitations Max of 10 amp through the terminals, thus the excess comes from the loose wires.
Amber is the mandatory 2 amp load for voltage stability, used when no or small current draw is applied.
Green turns on output.
LED to show mains is on.
Oh and I added an alaska blue light up fan to replace the crappy non light up old fan ^^
