Description
The MAS-38 (Manufacture d'Armes de Saint-Étienne 1938) is a French 7.65mm submachine gun designed prior to the outbreak of the Second World War.

The MAS-38 is easily recognizable due to its seemingly bent barrel assembly. This is because the receiver and butt diverge in alignment from the axis of the barrel by several degrees. To make the weapon compact its bolt recoils inside a tube running through the buttstock . To allow a natural aiming stance, the butt had to drop while the receiver had remain in alignment. This required that the bolt approach the breech at an angle and the face of the bolt was cut obliquely to allow it to close evenly on the cartridge. The MAS-38 also features an unusual safety catch: the bolt was locked (in either the forward or rear position) by pushing the trigger forward. A valuable feature was that tools were not required for its disassembly.

A very high quality weapon, the MAS-38 was machined from solid steel and only a few parts were stampings. It was designed with a buffered sear assembly to prevent wear and increase the life of the internal parts. A dual range sight system was concealed within the receiver so as to be out of sight until it was flipped up for use.

The odd appearance of the MAS-38 did not detract from its accuracy, but its cartridge was underpowered compared to the German 9mm standard pistol ammunition. However this cannot have made any difference to the outcome of the Battle of France, and in any event the German army seized the MAS plant in 1940 just as the MAS-38 was entering large-scale production. The Germans accepted the gun as a substitute standard weapon, naming it the 7.65 mm MP722(f). They continued production of the gun for their own armed forces and supplied some to the Vichy French.

Vector by me
