Description
A remaster and re-upload from Photobucket. Base Flanker courtesy of Gollevainen

The Shenyang J-16 (Chinese: 歼-16) is a tandem-seat, twinjet, all-weather, multirole strike fighter designed and manufactured by Shenyang Aircraft Corporation, China. This is a multi-role highly maneuverable variant based on the J-11BS with longer range and upgraded avionics, a concept equivalent to Sukhoi Su-35. The first few photos of J-16 were published on Chinese internet websites around June 2012. The J-16 has a slightly different vertical stabilizer compared to J-11 fighter or J-15 naval fighter. It is also equipped with missile pylons for Chinese PL-8 air-to-air missiles, another difference compared to earlier J-11 variants. According to media reports, China developed the Shenyang J-16 fighter based on the Shenyang J-11B airframe, with modifications from the Russian Sukhoi Su-30MKK that was sold to China in 2000.

GENERAL CHARACTERISTICS

    Crew: 2
    Length: 21.9 m (72 ft)
    Wingspan: 14.7 m (48.25 ft)
    Height: 6.36 m (20.85 ft)
    Wing area: 62.04 m2 (667.80 ft2)
    Empty weight: 17,700 kg (38,600 lb)
    Loaded weight: 26,000 kg (58,000 lb)
    Max. takeoff weight: 35,000 kg (77,000 lb)
    Powerplant: 2 × WS-10A afterburning turbofans
        Dry thrust: 89.17 kN (20,050 lbf) each
        Thrust with afterburner: 135 kN (33,000 lbf) each

PERFORMANCE

    Maximum speed: Mach 2.0
    Range: 3,900 km (2,400 mi)
    Service ceiling: 17,300 m (56,800 ft)
    Rate of climb: 305 m/s ()

ARMAMENT

    1 × 30 mm GSh-30-1 cannon with 150 rounds
    Munitions on twelve external hardpoints, including:
        8 × PL-12, and 4 × PL-9 air-to-air missiles
        Various bombs and rockets including BeiDou satellite-guided bombs and laser-guided bombs
        Anti-ship and anti-radiation missiles
        Electronic countermeasure (ECM) pods
