Bush1do — How to - Leopard on VMWare
Published: 2008-03-10 11:46:18 +0000 UTC; Views: 130752; Favourites: 44; Downloads: 2332
Redirect to original
Description
How to - Install Leopard on VMWare Download & Burn
Download a Leopard Image like iATKOS . Burn it on a DVDCreate & Edit your Virtual Machine
Create a Virtual Machine , you must set over 3GB !Over 512MB RAM and go to edit and set up your DVD Drive.
Go to the Folder where your Virtual Machine is saved . Open the .vmx config file with Editor and delete the complete Text in the Editor and paste this in the Editor :bios.bootDelay = "5000"
checkpoint.vmState = ""
checkpoint.vmState.readOnly = "FALSE"
config.version = "8"
deploymentPlatform = "windows"
displayName = "Leopard"
ehci.pciSlotNumber = "33"
ehci.present = "TRUE"
ethernet0.addressType = "generated"
ethernet0.connectionType = "nat"
ethernet0.generatedAddress = "00:0c:29:7b:c7:78"
ethernet0.generatedAddressOffset = "0"
ethernet0.pciSlotNumber = "32"
ethernet0.present = "TRUE"
ethernet0.virtualDev = "e1000"
ethernet0.wakeOnPcktRcv = "FALSE"
extendedConfigFile = "leopard.vmxf"
floppy0.autodetect = "TRUE"
floppy0.fileName = "A:"
floppy0.present = "FALSE"
guestOS = "freebsd-64"
ide0:0.fileName = "leopard.vmdk"
ide0:0.present = "TRUE"
ide0:0.redo = ""
ide1:0.autodetect = "FALSE"
ide1:0.deviceType = "cdrom-raw"
ide1:0.exclusive = "FALSE"
ide1:0.fileName = "Z:"
ide1:0.present = "TRUE"
memsize = "768"
mks.keyboardFilter = "allow"
monitor = "debug"
nvram = "leopard.nvram"
pciBridge0.pciSlotNumber = "17"
pciBridge0.present = "TRUE"
scsi0.pciSlotNumber = "-1"
scsi0.present = "FALSE"
scsi0.virtualDev = "lsilogic"
sound.autodetect = "TRUE"
sound.fileName = "-1"
sound.present = "FALSE"
svga.autodetect = "TRUE"
tools.remindInstall = "TRUE"
tools.upgrade.policy = "useGlobal"
usb.present = "FALSE"
uuid.action = "KEEP"
uuid.bios = "56 4d 50 97 29 7a 74 3f-a8 4a 39 81 24 7b c7 78"
uuid.location = "56 4d 50 97 29 7a 74 3f-a8 4a 39 81 24 7b c7 78"
virtualHW.productCompatibility = "hosted"
virtualHW.version = "6"
BIOS Properties
a. For the 2 IDE drives you need to set 32-bit I/O to enabled.
b. The floppy disk and chip must be disabled
c. Disable all serial and parallel ports
d. Large disk mode set to other
e. Boot order to CD first then Hard drive
Installing Leopard
Now you can boot from the CD if the Timer shows up press F8 and type in : -v cpus=1
If you've made all right you will be at the Install Screen .
Open Disk Utility to create a single partition and ensure that it is MBR based. Also make sure the volume label has no spaces in it.
Back in the installer select the new volume and then "Customize" button. If you have iATKOS then select the Darwin Bootloader if you have Zephyroth select the Chipset driver and the ToH SSE3 click on Bootloader and Select MBR or GUID look fist what youve i choose MBR !
Now sit back and wait while Leopard install .
Boot from Leopard Hard Drive
Now let Leopard boot from your Virtual Hard Drive , now you will see the Grey Apple Screen if that work youre done . But there can be a few Problems like this :
- Restarting always leads to a segment fault. So shutdown and power off then start up again.
- Sometimes it just won't restart with CPU fault. Best to shutdown VMware and restart.
- Network doesn't have a MAC address. This psi probably solvable but haven't had time to finish my work on this yet.
This Problems arent fixed !
Enjoy!
I hope that work for you . If you like it pls give it a
!(C) InsanelyMac ; Bush1do
VMX File hacked by Donk
Related content
Comments: 38
I'm looking for a tutorial which would show how to make a custom Windows 7, I know that much that I have to get my installation to audit mode and then make all my changes and stuff, and then capture the image and then convert the image or something.
Can you help me?
👍: 0 ⏩: 0
I keep getting the error "A virtual CPU has entered the shutdown state" is this because I haven't disabled the chip in BIOS? How do I? Because I couldn't find it PLZ HELP!!!
👍: 0 ⏩: 0
Thank for this guide - now I can install leopard on my vmware.
👍: 0 ⏩: 0
I dont get how using VMWare Workstation 7, lets me get full 1366x768 resolution, yet when i boot from a CD i burned it to, i get a kernel panic.
I used OSx86 version of iDeneb v1.4 OSX v.10.5.6.
👍: 0 ⏩: 0
Nice! Everything's gone well so far. I'm currently waiting for it to install, but the progress bar isn't moving anywhere, though. Will comment again if it still hasn't worked.
Also, I couldn't find "Darwin Bootloader" in the iAtkos 10.5.5 CD
👍: 0 ⏩: 0
i dont know if this still works with Snow Leopard but you deserve the Star anyway!
👍: 0 ⏩: 1
Yes it works. I used my Universal one. Search 10.6.2 Patched for PC UNIVERSAL on the pirate bay. It will be from cclloyd, about 300 seeds.
👍: 0 ⏩: 1
nice thanks, i might use it on some other pc in a near future, Snow Leo is running great my MSI x58 M Board with i7 920 and 3GB of RAM DDR3, i just did this for fun, made it install with Empire EFI
👍: 0 ⏩: 0
heyy man, i was wondering whether if you install iaktos for example, and choose the video, sound etc drivers, will they work? because im using the 10.5.5 VMWare image and the sound doesnt work, and the video drivers arnt installed, so you only get a laggy version of leopard that runs in 800x600?
👍: 0 ⏩: 0
v*** VMware Workstation internal monitor error ***
vcpu-0:ASSERT vmcore/vmm/cpu/segment.c:721 bugNr=19580
There is a problem in this version of VMware Workstation.
We rely on your feedback to improve the quality of our product. Please submit a support request that describes the problem at our Web page "[link] ". Do not forget to attach the log file (C:\Users\Daniel Steiner\Documents\Virtual Machines\Mac OSX 10.5.7\vmware.log) and the core file(s) (C:\Users\Daniel Steiner\Documents\Virtual Machines\Mac OSX 10.5.7\vmware-core.gz, C:\Users\Daniel Steiner\Documents\Virtual Machines\Mac OSX 10.5.7\vmware64-core.gz, C:\Users\Daniel Steiner\Documents\Virtual Machines\Mac OSX 10.5.7\vmware-vmx-debug-5712.dmp).
To collect data to submit to VMware support, select Help > About and click "Collect Support Data". You can also run the "vm-support" script in the Workstation folder directly.
We appreciate your feedback,
-- the VMware Workstation team. at VMware 7....
👍: 0 ⏩: 0
it worked dude thx,u r awesome... but resolution is 1024x768 max. how to fix it? Any method this proplems fix it, for example 1280x800 max resolution, u have an idea?
i use iatkos 10.5.5 leopard disc and it worked, but resolution and 1 core cpu working problem,very slow...
thx anyway...
👍: 0 ⏩: 0
I'm unable to reproduce your results.
I've set up a VM with 768MB RAM, 4GB virtual IDE hard drive, and I'm using the iATKOS_v7 ISO as my virtual DVD drive. In VMWare 6.5.3 build 185404 I get the following error message, right after entering "-v cpus=1" into the boot prompt:
*** VMWare Workstation internal monitor error ***
vcpu-0:ASSERT vmcore/vmm/cpu/segment.c:540 bugNr=19580
There is a problem in this version of VMWare Workstation...
(The rest, about posting a bug ticket, deleted)
I know this is an old post. Could you tell me which version of VMWare Workstation you were using when you created this guest? Also, there are about a dozen additional settings in the current .vmx file which are not present in yours; I've attempted to carefully merge the settings from your .vmx file above with my own. If I attempt to use yours, as-is, I don't even get that far.
👍: 0 ⏩: 0
does it have to be 3GB of memory? can it be any least then like 2GB or 1.5GB?
👍: 0 ⏩: 0
bro!!
i would be very thankful to u if u lead me with some help.
i downloaded a leopard image but i cant install it in vmware.i have the latest version but its not loading image(its in .iso)may be there is some fault in iso.if u can give me some rapid links of ur iso of os X i would be very thankful
👍: 0 ⏩: 2
Forgot to say, that DVD burner will "inflate" that ISO file on the DVD. "i.e, you won't see a .ISO file on the DVD, instead, you'll see its contents"
👍: 0 ⏩: 0
I'm just thinking loud. ISO files are usual DVD or CD images, you first need to use a DVD or CD burner that can read ISO and burn it on a DVD or CD.
Can you tell me where did you get that leopard image from ?
👍: 0 ⏩: 0
same issue here. plz help us, im stuck on the grey screen with no dvd drive activity
👍: 0 ⏩: 0
I am having the same issue as Spewboy
it hangs at that abstract picture and spinning cursor
👍: 0 ⏩: 0
Hello. After trying to get this to work for hours the best I've managed to do is get past the Apple logo and into the blue screen with the spinning cursor where it hangs. I had to change the OS from FreeBSD to Windows NT to get it this far.
Any ideas as to what to do now?
👍: 0 ⏩: 0
hello,
After replace .vmx file with above content and try to startup vmware image, I get this error:
Invalid configuration file: "D:\vmwareos\Mac105\FreeBSD 64-bit.vmx" was created by a VMware product with more features than this version of VMware Workstation and cannot be used with this version of WMware Workstation.
Cannot open configuration file: D:\vmwareos\Mac105\FreeBSD 64-bit.vmx
I'm using vmware 5.5.7 build 91707, what version is required? or do I have some other issues?
This is content of my D:\vmwareos\Mac105\FreeBSD 64-bit.vmx file:
bios.bootDelay = "5000"
checkpoint.vmState = ""
checkpoint.vmState.readOnly = "FALSE"
config.version = "8"
deploymentPlatform = "windows"
displayName = "Leopard"
ehci.pciSlotNumber = "33"
ehci.present = "TRUE"
ethernet0.addressType = "generated"
ethernet0.connectionType = "nat"
ethernet0.generatedAddress = "00:0c:29:7b:c7:78"
ethernet0.generatedAddressOffset = "0"
ethernet0.pciSlotNumber = "32"
ethernet0.present = "TRUE"
ethernet0.virtualDev = "e1000"
ethernet0.wakeOnPcktRcv = "FALSE"
extendedConfigFile = "leopard.vmxf"
floppy0.autodetect = "TRUE"
floppy0.fileName = "A:"
floppy0.present = "FALSE"
guestOS = "freebsd-64"
ide0:0.fileName = "leopard.vmdk"
ide0:0.present = "TRUE"
ide0:0.redo = ""
ide1:0.autodetect = "FALSE"
ide1:0.deviceType = "cdrom-raw"
ide1:0.exclusive = "FALSE"
ide1:0.fileName = "Z:"
ide1:0.present = "TRUE"
memsize = "768"
mks.keyboardFilter = "allow"
monitor = "debug"
nvram = "leopard.nvram"
pciBridge0.pciSlotNumber = "17"
pciBridge0.present = "TRUE"
scsi0.pciSlotNumber = "-1"
scsi0.present = "FALSE"
scsi0.virtualDev = "lsilogic"
sound.autodetect = "TRUE"
sound.fileName = "-1"
sound.present = "FALSE"
svga.autodetect = "TRUE"
tools.remindInstall = "TRUE"
tools.upgrade.policy = "useGlobal"
usb.present = "FALSE"
uuid.action = "KEEP"
uuid.bios = "56 4d 50 97 29 7a 74 3f-a8 4a 39 81 24 7b c7 78"
uuid.location = "56 4d 50 97 29 7a 74 3f-a8 4a 39 81 24 7b c7 78"
virtualHW.productCompatibility = "hosted"
virtualHW.version = "6"
thx!
👍: 0 ⏩: 0
ich versuch mal das ganze in virtual box zu installiern
👍: 0 ⏩: 0
hi,
i've burned the iAtkos 2.0i to a DVD and ran the DarwinBoot. After waiting and some text loading down the screen I either get a blue screen with the pretty cursor which gets stuck and doesn't move on; or the grey apple screen which then has a "no-smoking" sign appear.
do you have any idea what i need to do to get to the install screen?
👍: 0 ⏩: 1
i'm having the same problem. any solution yet?
👍: 0 ⏩: 0
Sorry if this is a silly question, but does this not work on amd??? I've tried everything a million different ways and cannot get anywhere...
👍: 0 ⏩: 0
hm , did you use intel or amd?
👍: 0 ⏩: 0
