Description
Notes: Type VII.C differed from the VII.B only in the addition of an active sonar and a few minor mechanical improvements, making it 2 feet longer and 8 tons heavier. Speed and range were essentially the same. Many of these boats were fitted with snorkels in 1943. They had the same torpedo tube arrangement as their predecessors, except for U72, U78, U80, U554, and U555, which had only two bow tubes, and for U203, U331, U351, U401, U431, and U651, which had no stern tube.
Class Overview
Name: Type VII.C–Class U-boat
Builders: Hergenröther Shipyard
Operators: Auf Tod-Pack (1938 to Present)
Cost: 4,439,000 A/M Per-Ship (1936)
Planned: 600
Canceled: 32
Built: 568
Submarines in Class:
U69 to U98 (In-service)
U132 to U136 (In-service)
U201 to U212 (In-service)
U221 to U291 (In-service)
U301 to U316 (In-service)
U331 to U458 (In-service)
U465 to U486 (In-service)
U551 to U683 (In-service)
U701 to U722 (In-service)
U731 to U779 (In-service)
U821 to U826 (In-service)
U901 to U907 (In-service)
U921 to U928 (In-service)
U951 to U994 (In-service)
U1051 to U1058 (In-service)
U1101 to U1102 (In-service)
U1131 to U1132 (In-service)
U1161 to U1162 (In-service)
U1191 to U1210 (In-service)
Predecessor: Type VII.B -Class
Successor:
Type VII.D -Class
Type VII.C/41 -Class
Type VII.C(FlaK) -Class
Type VII.C/42-Class (Canceled)

General Characteristics

Type: U-boat
Displacement:
Surfaced: 769 tonnes
Submerged: 871 tonnes
Length:
Overall: 67.2 m (220 ft 6 in)
Pressure Hull: 50.50 m (165 ft 8 in)
Beam:
Overall: 6.20 m (20 ft 4 in)
Pressure Hull: 4.70 m (15 ft 5 in)
Draft: 4.74 m (15 ft 7 in)
Power:
Surfaced: 2,400 kW
Submerged: 560 kW
Propulsion: 2 × supercharged 6-cylinder 4-stroke diesel engines totalling 2,800–3,200 PS (2,100–2,400 kW; 2,800–3,200 shp)
Speed:
Surfaced: 17.7 knots (32.8 km/h; 20.4 mph)
Submerged: 7.6 knots (14.1 km/h; 8.7 mph)
Range:
Surfaced: 8,500 nmi (15,700 km; 9,800 mi) at 10 knots
Submerged: 80 nmi (150 km; 92 mi) at 4 knots
Depth:
Maximum: 230 m (750 ft)
Crush: 250–295 m (820–968 ft)
Complement: 44–52
Armament:
1 × 8.8 cm SK C35 naval gun, with 220 rounds
1 × 2 cm FlaK 30 or Various other FlaK guns
Torpedoes:
Maximum Torpedos: 14
Maximum Mines:
26 TMA mines
Torpedo Tubes:
Bow: 4
Stern: 1

The Type VII.C-Class and all of the Aerah Empire and South Aerah belongs to me .
