Description

Project 20 under the Revised Post-Dreadnought Naval Development Scheme was a class of three light cruisers which served with the Hosh Navy between 1933 to 1942 and were the first Hosh cruisers designed with a modern cruiser scheme. L̶i̶k̶e̶ m̶a̶n̶y̶ o̶f̶ H̶o̶s̶h̶' f̶u̶t̶u̶r̶e̶ m̶o̶d̶e̶r̶n̶ c̶r̶u̶i̶s̶e̶r̶ d̶e̶s̶i̶g̶n̶s̶, t̶h̶e̶ P̶r̶o̶j̶e̶c̶t̶ 2̶0̶ c̶r̶u̶i̶s̶e̶r̶s̶ w̶e̶r̶e̶ n̶o̶t̶a̶b̶l̶y̶ t̶o̶p̶-̶h̶e̶a̶v̶y̶ a̶n̶d̶ r̶o̶l̶l̶e̶d̶ d̶a̶n̶g̶e̶r̶o̶u̶s̶l̶y̶ i̶n̶ r̶o̶u̶g̶h̶ s̶e̶a̶s̶. (Thanks to eltf177 for putting the ship into Springsharp, turns out the ship isn't unstable at all) Their main armament consists of a battery of eight 15cm (5.9in) guns and twelve 50cm (20in) torpedo tubes.

M-1, M-2 and M3 served mainly as training cruisers during the ceasefire period. The three ships received refits in the 1940s such as replacing the outdated AA armament and updating the secondaries and ressigned as fleet escorts. All three ships were damaged in combat and were forced to retreat, but where hunted down by Coalition bombers and sunk.

Displacement: 8,600 t

Length:
Waterline: 164.7m
Overall: 169.2m

Beam: 14.8.0m

Draft: 5.4m

Installed Power:
70,000shp (52,000 kW)

2 diesel engines

Propulsion:
2 screws; 4 steam turbines

Speed:
32.5 knots

Range:
5,000 nautical miles (9,260 km) at 17 kn (31 km/h)

Compliment:
500

Armaments:
8 × 150mm (5.9") guns in two four-gun turrets
12 × 105mm (4.1") DP guns in six two-gun turrets
32 × 30mm AA guns in eight quadruple mounts

Armor:
Belt: 40mm
Barbettes: 30mm
Deck: 20mm
Turrets: 20-30mm

Aircraft:
1 seaplane

I'll be honest with you, the only reason why I even started on this was because I wanted to put a quad turret superfiring over some secondary guns. Weren't even suppose to be two secondaries in front of each turret, reduced the secondary from 128mm to 105 and felt there was now too much space

Also added park benches, since it's french influenced

Eclipse ate the description. Fixed now

Redid the stats, they're not identical to the ones on the card anymore as some details had to be changed

Made with Sketchup
