Description

The Sonorous-class is a class of five heavy cruisers which served the Kingdom of Elipida between 1915 to 1944 with all ships being sunk by accidents or enemy fire.

They were originally designed and built as improved light cruisers meant to counter foreign armored cruisers armed with 7in guns. Under the 1922 Naval Treaty Proposal, they would have been reclassified as heavy cruisers, however the treaty collapsed due to political bickering between powers and the inability to force anyone to comply with the limitations. While Elipida was free to keep their original designation, it was eventually decided that the ships be reclassified and serve as the starting point for all future 'small-caliber' heavy cruisers (as the majority of already existing improved armored cruisers were armed with 10.5in guns)

Brenthill had the shortest career, as within a year of commission she ran aground and could not be refloated. Cartgonie and Birher served as convoy escorts and were both sunk by enemy action. Sonorous and Deadwall served as fleet escorts in Task Force 40 and participated in the Königskind Incident, where their crews were vaporized by the Hosh superweapon. While the ships were largely intact, it was not possible to board them without becoming fatally ill. Both ships, along with all ships in Task Force 40, were scuttled.

Displacement:
8,002 t light; 8,409 t standard; 8,992 t normal; 9,459 t full load

Dimentions: Length overall / water x beam x draught
153.13 m / 151.60 m x 17.00 m x 6.50 m (normal load)

Installed Power:
77,500 shp / 57,815 Kw

Oil fired boilers, steam turbines
Geared drive, 4 shafts

Speed:
31 knots

Range:
9,000 nautical miles (16,670 km) at 10 kn (18.5 km/h)

Compliment:
460-600

Armaments:
8 × 203mm (8") guns in four two-gun casemate turrets - limited use in heavy seas
8 × 127mm (5") guns in eight casemate turrets
60 × 28mm (1.1") AA guns in fifteen quadruple mounts
4 × 28mm (1.1") AA guns in two twin mounts
10 × 20mm AA guns in ten mounts
8 × 533mm (21") torpedo tubes in four twin mounts

Armor:
Belt - Main: 127mm
Belt - Ends: 64mm
Belt - Upper: 38mm
Deck: 38mm
Turrets: 51mm
Conning tower: 51mm

Meant to post this a few weeks ago lol

Also did the numbers in Springsharp for once. As I tend to make the ship before I look into Springsharp, the painted draft and the one it gave me are different
