Description
Notes: The type VII.D U-boats, designed in 1939 and 1940, were a lengthened – by 10 m (32 ft 10 in) – version of the VII.C for use as a minelayer. The mines were carried in, and released from, three banks of five vertical tubes just aft of the conning tower . The extended hull also improved fuel and food storage.
Class Overview
Name: Type VII.D–Class U-boat
Builders: Hergenröther Shipyard
Operators: Auf Tod-Pack (1940 to Present)
Cost: 4,835,000 A/M Per-Ship (1940)
Planned: 10
Canceled: 4
Built: 6
Submarines in Class:
U213 (In-service)
U214 (In-service)
U215 (In-service)
U216 (In-service)
U217 (In-service)
U218 (In-service)
Predecessor: Type VII.C -Class

Successor:
Type VII.E-Class (Canceled)
Type VII.F -Class

General Characteristics

Type: U-boat
Displacement:
Surfaced: 965 tonnes
Submerged: 1080 tonnes
Length:
Overall: 76.9 m (252 ft 4 in)
Pressure Hull: 59.8 m (196 ft 2 in)
Beam:
Overall: 6.28 m (20 ft 7 in)
Pressure Hull: 4.70 m (15 ft 5 in)
Draft: 5.01 m (16 ft 5 in)
Power:
Surfaced: 2,400 kW
Submerged: 560 kW
Propulsion: 2 × supercharged 6-cylinder 4-stroke diesel engines totalling 2,800–3,200 PS (2,100–2,400 kW; 2,800–3,200 shp)
Speed:
Surfaced: 16.7 knots (30.9 km/h; 19.2 mph)
Submerged: 7.3 knots (13.5 km/h; 8.4 mph)
Range:
Surfaced: 11,200 nmi (20,700 km; 12,900 mi) at 10 knots
Submerged: 69 nmi (128 km; 79 mi) at 4 knots
Depth:
Maximum: 200 m (660 ft)
Crush: 220–240 m (720–790 ft)
Complement: 46–52
Armament:
1 × 8.8 cm SK C35 naval gun, with 220 rounds
2 × 2 cm Flak C30 with 4,380 rounds
Torpedoes:
Maximum Torpedos: 14
Maximum Mines:
15 SMA mines in
vertical chutes and
either 26 TMA mines or
39 TMB mines
Torpedo Tubes:
Bow: 4
Stern: 1

The Type VII.D-Class and all of the Aerah Empire and South Aerah belongs to me .
