SoloAD — Russian monitor Navarin
Published: 2012-03-04 20:52:55 +0000 UTC; Views: 9164; Favourites: 43; Downloads: 143
Redirect to original
Description
Водоизмещение: 9860/10640т; 111,9х26,9х5,67м; 4 диз., 4000 л.с., 11 уз.; 450 т. соляра; 5600(12) миль. Эк. 480 чел. Броня: палуба 200мм, скосы 250мм, рубка 400 мм, башня ГК 250-400 мм, барбет ГК 300-375мм, башни и барбеты СК – 50мм, переборка ПТЗ – 40мм. 1х3-406 мм/45, 4х2 – 130 мм/50, 6х2 – 37 мм/67, 8х1 – 12,7 мм пул.More info: solo-ad.livejournal.com/1622.h…
Related content
Comments: 9
👍: 2 ⏩: 0
Interesting design, and very beautifully rendered, though I wonder about the draft being enough to accommodate that huge barbette--I'd think even raised, the design is pushing things regarding deck penetration. I may attempt a Springsharp rendering to see what I can come up with, regards simming it, if I can figure out all the specs.
👍: 0 ⏩: 1
I tried to calculate the data in springsharp, but the result was unsuccessful.
👍: 0 ⏩: 0
Excellent work! I love the less known coastal Monitors.
When was commissioned?
👍: 0 ⏩: 1
Yes, the Russian fleet after WWI.
👍: 0 ⏩: 0
