MMD3DCGParts — MMD Tutorial Stop the model from crashing MMD
#3dcg #3dcustomgirl #mmd #mikumikudance
Published: 2014-11-10 16:21:23 +0000 UTC; Views: 32708; Favourites: 404; Downloads: 238
Redirect to original
Description
Panel 1 - Ahh! I worked so hard on this edit and it just crashes MMD! I'm giving up on this edit..."Don't give up yet I will show you how to fix this"
Panel 2 - First lets check the bones, well the bones look good lets check on the other things.
Panel 3 - Well that's a problem.
Panel 4 - When you are done getting all the physics selected press "Edit" -> "Selected(O)" -> "Del Bone/Physic/Joint Del"
Side note - Un-needed physics may not crash MMD but it does mess up the model while dancing. Like making the skirt spazz even more then it started with.
Panel 5 - God this will take years to clean!
"No not really"
Panel 6 - Go to the joint tab.
You see alot of the un-needed joints have the same ending. ( Like a repeat like Joint A --> AAAAA --> AAAAA in most cases they will be attached to the same thing or even left blank)
Well those are the ones you need to remove.
A easy way to do it is by clicking the last joint on the list and going to your "Delete" key on your keyboard then just click "OK".
Side note - Make sure to keep an eye on what your deleting because you may remove some important joints. Oh yeah another thing if you have alot of un-connected joints it may make PMDE not work right.
Panel 7 8 - Now she's clean and the model doesn't crash MMD~!
Side note - If you can't find all the un-needed joints and physics, you are better off just restarting the model and making sure each part it cleaned before you add it to the base your using.
This is not the case for all crashes of MMD. Sometimes it's bones which I can't really help you on that.
If none of this works/helps start the model over. That's all I can say/do to help anyone if they are still having problems with the model, sorry.
Also read the comments.
Model -
Person that messed up the models joints and physics on purpose
Related content
Comments: 155
So, from what I see, you use PMX.
Go to File and to the last option. A little window will pop up and anything that says bad should be fixed. Use Google translate to get an idea as to what needs to be fixed.
👍: 0 ⏩: 0
PLZ help, i've made a model and everytime i try to load it into MMD it closes the program. IDK Y
👍: 0 ⏩: 0
OK update, i do, but i don't have any extra joints
👍: 0 ⏩: 0
I deleted all unnecessary joints and the rest I absolutely need. It still crashes though....Just not as fast as it did.
👍: 0 ⏩: 0
Please help me with this fucking mess of a model...
I have no clue which bodies to delete.
I deleted all her joints since I have no intention of using physics whatsoever
And I deleted all unwanted bones.
Idk what else to do... Please help!!!
👍: 0 ⏩: 0
How do I do this for just... hair models to practice adding bones/physics? I did one ponytail on a pigtail hair model I was using as practice to add bones and weight, and when I went to load it into MMD, it just crashed.
👍: 0 ⏩: 0
I can open the model in PMX editor fine, and the model can be tested in the transform view and it looked pretty well. The model was made with a head and body part. For some reason I can load the body into MMD just fine, but when it comes to loading the head my MMD keeps crashing... Anyone has any ideas?
P.S. I also tried the method above already.
👍: 0 ⏩: 0
okay so when i fixed the model, the anger morph (the red veins thingy) kind of joined with the mouth morphs (the a, e, i, o, u) and i cant seem to fix it D:
like, say i opened the mouth, the veins would show up with it and its really annoying
pls halp
👍: 0 ⏩: 0
Thankyou so much!!! I've been trying to fix this for hours!
👍: 0 ⏩: 0
It worked you can't describe how happy I am!!!! I LOVE YOU!!!!!!! Hallelujah!!!!!
👍: 0 ⏩: 0
I fixed my model and he seems to load all right in MMD, but once I turn on the physics to test (the problem I was trying to fix was his hair flapping around and going crazy when the physics are on) MMD crashes. I was removing extra physics left over from the hair that came with the base I used, and removing extra bones and joints. And I honestly have no idea what's going on here- usually if MMD crashes it's when I first try to load the model in.
👍: 0 ⏩: 0
I tried everything 100 times. It's getting better, but she crashes just directly before she loads in. PLS HELP
👍: 0 ⏩: 0
I did this with every model in my project and it's still crashing ;A; do you know what else could be crashing it?
👍: 0 ⏩: 1
Thank you for this tutorial, btw! My models DID have these problems, and I'm glad I was able to fix them before they caused anything :3
👍: 0 ⏩: 0
I have an insanely strange problem.
I open my model in PMX editor.
I just change the info/comments/text box where I put my rules
I type my rules
I save
It crashes MMD when it didn't crash before.
I SWEAR the only thing I'm touching is that text box.
👍: 0 ⏩: 0
My model doesn't have any of those and I cannot figure out why she crashes... There aren't any extra joints but it is really annoying when I go in and the model has way too many dress bones that it makes it near impossible to see through.
Any suggestions?
👍: 0 ⏩: 0
;-; I've deleted the unneeded joints but my model still keeps on crashing
👍: 0 ⏩: 0
OMFG THANK U SOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOO MUCH
👍: 0 ⏩: 0
Im trying to load my mmd project and its crash ;-; btw this is a good tutorial
👍: 0 ⏩: 0
The things is when i open up the MMD model on my own it's didn't crash but when other people do on their computer it crash...T-T someone help me!!
👍: 0 ⏩: 0
i don't have extra joint, but i can't open her, what should i dooooo T^T
👍: 0 ⏩: 0
Hey I'm wondering how do you tell apart the not needed yellow squares from the needed ones?
👍: 0 ⏩: 1
For example, my base model has 60 joint (yellow squares), I imported a skirt but it imported 80 other joints, so I have 140 joints now !
-I displayed the yellow square on my new model, and went in the joint menu.
-I know that the 60 first ones are the base model's joints = I NEED THEM, so I will begin to check the new ones from n°61 to n°140
-Among these new ones I will check every of them and only keep those located on the skirt, the other ones can be deleted
-At the end my new model has the 60 base joints + 20 from the skirt, so I only have 80 joints that are needed.
👍: 0 ⏩: 1
I had figured it out, the download was borked, lol
👍: 0 ⏩: 0
Thank you so much for making this tutorial! I was legit going to cry last night after working so hard on the model
👍: 0 ⏩: 0
My model has none on these thing.s It's still crashing. Help?
👍: 0 ⏩: 0
Can u help me? I tried making models but When i put clothes that have skirt....the skirt keep melting the physic and joint is right on it place
PLEASE HELP ME
👍: 0 ⏩: 0
I tried to clean up the physics on some of my models and it made them crash MMD! I don't know what happened! (Thankfully I kept a version of those models that I didn't fix the physics on)
👍: 0 ⏩: 0
THIS LITERALLY SAVED ME FROM THROWING MY COMPUTER OUT THE WINDOW!!! THANK YOU THANK YOU THANK YOU!!!!
👍: 0 ⏩: 0
could i get help with lip syncing? I Would Love Some Help Please TT-TT. i load up the wav and play it but when i start adding in the mouth movements and play it the mouth starts slowly opening before it reaches the actual mouth movement frames also when adding in the mouth movement frames the mouth starts to stick with another mouth frame causing the mouth to have to mouth frames open when i only want one
👍: 0 ⏩: 0
um...MMD3DCGParts my friend made me a model but the model is always crashing and my friend is trying to fix it and she check all the physics and joints and everything was fine. Do you think you could help us?
👍: 0 ⏩: 1
That's the same problem with mine, I checked all joint's hidden bones and vertex and it still crashes it
👍: 0 ⏩: 2
my friend of a friend fixed it i dont know how
👍: 0 ⏩: 1
; -; wish I had your friend lol ive been trying from PMX Editor to PMD Editor and MMD just won't take any models I make
👍: 0 ⏩: 1
Is it where you just do stuff andf it crashes? ..i dont know..im helpless
👍: 0 ⏩: 1
Sorry on this late response could not remember my pass for the life of me XD
Well after I make her on PMX Editor I go into the actual MMD program and when I try to upload her in it crashes
👍: 0 ⏩: 0
I need help it still crashes... Can someone do it for me? I've been working on it for sooo long and can't fix it ;-;
👍: 0 ⏩: 0
IT STILLS CRASHING!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
👍: 0 ⏩: 1
It may be a bone problem, or simply a problem with your MMD.
👍: 0 ⏩: 0
My model turns into a puddle when i turn the physical operations on. Is that related to the joints or the physics?
👍: 0 ⏩: 1
This won't solve that problem.
To fix it -
1 - Go to the first joint of the hair (just using hair as a example) and click it
2 - Go to the to boxes under were you name the joint. It should be Box 1 - Head Box 2 - Hair 1
It shouldn't be Box 1 - Hair 1 Box 2 - Hair 1 or anything like that. The first part should be attached to the solid/non-moving physic since that's what keeps the physic/joints in place of a model.
If it's a chain of moving physics and joints it should be like this "Joint 1 Box 1 - Head Box 2 - Hair 1" "Joint 2 Box 1 - Hair 1 Box 2 - Hair 2" and so on like that.
👍: 0 ⏩: 1
Yeah I got it fixed thanks. I don't quite understand the physics but I personally won't be using them and if anyone using my models wants to then they'll need to add them until I understand it. Thanks for the help anyway
👍: 0 ⏩: 1
